PERFORMANCE
Processor
AMD Ryzen™ Z2 Go (4C / 8T, 3.0 / 4.3GHz, 2MB L2 / 8MB L3)
Graphics
Integrated AMD Radeon™ Graphics
Chipset
AMD SoC Platform
Memory
16GB Soldered LPDDR5x-6400
Memory Slots
Memory soldered to system board, no slots
Max Memory
16GB soldered memory, not upgradable
Storage
512GB SSD M.2 2242 PCIe® 4.0×4 NVMe®
Storage Support
One drive, up to 1TB M.2 2242 SSD
Storage Slot
One M.2 2280 PCIe® 4.0 x4 slot
Card Reader
microSD Card Reader
Optical
None
Audio Chip
High Definition (HD) Audio
Speakers
Stereo speakers, 2W x2
Camera
None
Microphone
2x, Array
Battery
55.5Wh
Power Adapter
65W USB-C® Slim (2-pin, Wall-mount)
Special Features
Legion Cold front cooling system
DESIGN
Display
8″ WUXGA (1920×1200) IPS 500nits Glossy / Anti-fingerprint, 100% sRGB, 48-120Hz VRR, Panda King Glass, Low Blue Light, Touch
Touchscreen
In-cell, 10-point Multi-touch
Touchpad
Buttonless Mylar® surface touchpad (on the right controller), 10 x 10 mm (0.39 x 0.39 inches)
Case Color
Glacier White
Surface Treatment
Painting + Laser Special Texture
Case Material
PC-ABS + 15% Talc
Pen
Pen Not Supported
Controls
A B X Y buttons D-pad Touchpad Left & right Joysticks 4x function buttons Y1 & Y2 buttons LT & RT buttons LB & RB buttons LT & RT button range switch
Dimensions (WxDxH)
298.5 x 127.55 x 22.6-43.4 mm (11.75 x 5.02 x 0.89-1.71 inches)
Weight
Around 740 g (1.63 lbs)
Others
-Power button
-Volume keys
SOFTWARE
Operating System
Windows® 11 Home Single Language, English
Bundled Software
Office Trial
CONNECTIVITY
Ethernet
No Onboard Ethernet
WLAN + Bluetooth
AMD Wi-Fi® 6E RZ616, 11ax 2×2 + BT5.3
WWAN
Non-WWAN
Standard Ports
2x USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4)
1x Headphone / microphone combo jack (3.5mm)
1x Card reader
Docking
Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for Legion Go S 8ARP1
SECURITY & PRIVACY
Security Chip
Firmware TPM 2.0 Enabled
Fingerprint Reader
None
SERVICE
Base Warranty
1-year, Courier or Carry-in
Included Upgrade
2Y Depot/CCI -IPENTRY (ESS)
ACCESSORIES
Bundled Accessories
None
CERTIFICATIONS
Green Certifications
ErP Lot 6/26
RoHS compliant
Other Certifications
TÜV Rheinland® Low Blue Light (Hardware Solution)
MODEL INFORMATION
Model
83L3000NPH
Country/Region
Philippines
Top Seller
Yes
EAN / UPC / JAN
198155500275
